Name: Mixer Truck Sinotruk Heavy Duty HOWO 12m3 6X4 Construction Coment Concrete
Brand: Chengli Special Co., Ltd.
SKU: HW19710
Price: 20.00 USD
Availability: InStock

Home > Products > Concrete Mixer Truck >

Mixer Truck Sinotruk Heavy Duty HOWO 12m3 6X4 Construction Coment Concrete

12m3 Concrete Mixer Truck

HOWO Concrete Mixer Truck

6X4 Concrete Mixer Truck

Place of Origin:

suizhou hubei

Brand Name:

howo

Certification:

ISO, CCC,SGS,BV

Model Number:

HW19710

Request A Quote

Mixer Truck Sinotruk Heavy Duty HOWO 12m3 6X4 Construction Coment Concrete

Product Details

Type:

In-line 6-cylinder, Water-cooled, Supercharged, Inter-cooled, Electric (Direct) Injection Diesel Engine

Model:

WD615.47

Tyre:

12.00R20

Driving Type:

6*4

Gear Box:

HW19710

Outline Dimension(L*B*H) (mm):

9040×2496×3850(mm)

Total Vehicle Weight (Kg):

25000

Curb Weight (Kg):

10450

Chassis:

HOWO

Max Power (KW):

371 HP(2200rpm)

Drum Capacity:

12cbm

Highlight:

12m3 Concrete Mixer Truck

HOWO Concrete Mixer Truck

6X4 Concrete Mixer Truck

Payment & Shipping Terms

Minimum Order Quantity

1unit

Price

USD33,008-USD50,000

Delivery Time

20days

Payment Terms

L/C, T/T

Supply Ability

200unit/year

Dongfeng 6*4 10 Cubic Meters Cement Mixing Truck With 13870kg Curb Weight

Get Best Price

13870kg Curb Weight JAC Redi Mix Concrete Truck And truck ready mix

Get Best Price

Euro 3 Foton Small 3 Cubic Meters Concrete Mixer Truck 83 Max Speed(Km/H) Truck Mixer Truck

Get Best Price

Jiefang Concrete Cement Mixer Truck 13890 Kg Diesel Concrete Mixer For Truck

Get Best Price

Contact Now

Product Description

Mixer Truck Sinotruk Heavy Duty HOWO 12m3 6X4 Construction Coment Concrete

Product Description:

The concrete mixing transport vehicle is composed of an automobile chassis and a special device for concrete mixing transport.

The chassis of concrete mixing transporters produced in our country mostly adopts the second type general chassis provided by vehicle manufacturers. The special mechanism mainly includes force extractor, stirring cylinder before and after support, reducer, hydraulic system, stirring cylinder, operating mechanism, cleaning system and so on. The working principle is that the power of the car chassis is taken out by the force taking device, and the variable pump of the hydraulic system is driven, the mechanical energy is converted into hydraulic energy and transmitted to the quantitative motor, the motor drives the reducer, and the reducer drives the mixing device to stir the concrete.

Technical Parameters:

Parameter	Value
Curb Weight (Kg)	10450
Chassis brand	SINOTRUK HOWO
Emission	Euro 5
Total Vehicle Weight (Kg)	25000
Outline Dimension(LBH) (mm)	9040×2496×3850(mm)
Fuel Type	Diesel
Gear Box	HW19710
Driving Type	6*4
Steering Mechanism	ZF8118
Front Axle	HF9 Drum

Product	Concrete Mixer Truck
Rear Axle	HC16
Service Brake	Dual-circuit Air Brake
Parking Braking	Spring-powered Air-cut-off Brake
Auxiliary Brake	Engine Exhaust Brake
Tyre	12.00R20
Model	WD615.47
Type	In-line 6-cylinder, Water-cooled, Supercharged, Inter-cooled, Electric (Direct) Injection Diesel Engine
Emission Standard	Euro II
Displacement	9.726(L)
Max Power (KW)	371 HP(2200rpm)
Drum capacity	12cbm
